BRADY PermaSleeve PS-187-2-BK-S Heat Shrink Wire Labels 3/16”, 3" Core Printers
BRADY PermaSleeve PS-187-2-BK-S Heat Shrink Wire Labels 3/16”, 3" Core Printers
Regular price
$99.99
Regular price
Sale price
$99.99
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Overview
PermaSleeve® PS Heat-Shrink Polyolefin (B-342) wire marking sleeves combine speed, ease of use, and permanence to create long-lasting, high quality identification.
- 3:1 heat shrinkable sleeve fit snugly around wires for maximum insulation protection and permanent identification
- Fade-resistant and smudge-proof for superior aesthetic appearance
- Cold resistant and flame-retardant with an operating temperature of -67°F to 275°F (-55°C to 135°C)
- Meets SAE-AMS-DTL-23053/5C (Class 1), SAE-AS-81531, MIL-STD-202;RoHS Compliant;and UL Recognized
- This roll has i75-series smart properties on the core that when used in the Brady i7500 printer in conjunction with i75-series smart ribbons, eliminates the need to adjust heat, speed , sensor location and mode, eliminates the need to calibrate out blank wasted labels, and warns the operator if a non-approved ribbon is used with this roll.
- If this roll is used in Brady i5100 or IP model printers it will function with smart operation in those printers with the exception that the Supply Remaining gauge on the display may be overstated. Contact Brady tech support for further information.
- If used in any other 3 inch core printer this roll will function as a manual roll
- A ribbon is required to print this material. Use Part Number IP-R6700-WT for the BradyPrinter i5100 or BRADY IP® Series Label Printer; use R6700-WT for a different printer
Specifications
| Key Characteristics | Catalog Page # | 198 |
| Product Number | 112519 | |
| UPC | 662820915461 | |
| UOM | Roll of 500 Each | |
| Quantity per Roll | 500 | |
| Unit Price | ||
| Trade Name | PermaSleeve® | |
| Brand Name | Brady® |
| Dimensions | Dimensions | 0.335 in H x 2 in W |
| Height | 0.335 in | |
| Width | 2 in | |
| Sleeve Size | 0.187 in Dia x 2 in W | |
| Vertical Repeat | 0.625 in | |
| Recovered Diameter | 0.062 in | |
| Recovered Wall Thickness | 0.02 in | |
| Web Width | 3.49 in | |
| Diameter as Supplied | 0.187 in | |
| Core Diameter | 3 in |
| Material Characteristics | Material Number | B-342 (View Technical Data Sheet) |
| Material | Heat-shrink Polyolefin | |
| Material Properties | Flame-retardant, Heat-shrinkable | |
| Label Properties | Heat Shrink | |
| Finish | Matte | |
| Color | Black | |
| Resistance Properties | Chemical-resistant, Corrosion-resistant, Humidity-resistant, Smear-resistant, UV-resistant, Weather-resistant | |
| Shrink Ratio | 3:1 | |
| Service Temperature Range °F | -67 °F - 275 °F |
| Product Features | Application | Electrical Labeling, Wire and Cable Labeling |
| Continuous or Die-cut | Die-cut | |
| Printable Sides | Single-Side Printable | |
| Quantity per Row | 1 | |
| Sleeve Slits | No |
| Printing Specifications | Print Technology | Thermal Transfer |
| Compatibility | Printer Compatibility | BBP72, i5100, i6100, i7100, i7500, IP Series, PR Plus, THT 3" Core Printers |
| Recommended Ribbon | i75-R6700-WT, IP-R6700-WT, R6700-WT | |
| Wire Diameter Range | 0.062 in - 0.15 in | |
| Wire Gauge Range | 20 AWG - 10 AWG |
| Compliance | California Prop 65 | |
| REACH SVHC Status | Please contact our CS department for more information | |
| REACH Candidate List Date | Please contact our CS department for more information | |
| Country of Origin | United States of America | |
| SAE | SAE 23053/5, SAE AS-5942, SAE AS81531 | |
| ECCN (Export Commodity Control Number) | EAR99 | |
| HTS Code (Harmonized Tariff Schedule) | 8443.99.2550 | |
| UL | UL224 | |
| RoHS Compliance Status | Please contact our CS department for more information | |
| UNSPSC | 39131502 |
